High-Performance Wide-Area Wi-Fi with UniFi® Mesh Technology. Breakthrough Speeds up to 1300 Mbps in the 5 GHz Band. 802.3af PoE Compatibility.
UniFi® is the revolutionary Wi-Fi system that combines enterprise performance, unlimited scalability, and a central management controller. The UniFi AC Mesh APs have a refined industrial design and can be easily installed using the included mounting hardware.
Easily accessible through any standard web browser and the UniFi mobile app (iOS or Android), the UniFi Controller software is a powerful software engine ideal for highdensity client deployments requiring low latency and high uptime performance.
Use the UniFi Controller software to quickly configure and administer an enterprise Wi-Fi network – no special training required. RF map and performance features, real-time status, automatic UAP device detection, and advanced security options are all seamlessly integrated.
• Save Money and Save Time UniFi comes bundled with a non-dedicated software controller that can be deployed on an on-site PC, Mac, or Linux machine; in a private cloud; or using a public cloud service. You also have the option of using the UniFi Cloud Key with built-in software.
• Powerful Hardware The UniFi AC Mesh APs feature Wi-Fi 802.11AC with Plug & Play Mesh technology.
• Intuitive UniFi Controller Software Configure and manage your APs with the easy-to-learn user interface.
• Expandable Unlimited scalability: build wireless networks as big or small as needed. Start with one and expand to thousands while maintaining a single unified management system.
• Networking Interface (1) 10/100/1000 Ethernet Port
• Buttons Reset
• Power Method 24V Passive PoE (Pairs 4, 5+; 7, 8 Return); 802.3af Alternative A (Pairs 1, 2+; 3, 6 Return) (Supported Voltage Range: 44 to 57VDC)
• Power Supply 24V, 0.5A Gigabit PoE Adapter*
• Power Save Supported
• Maximum TX Power 2.4 GHz, 5 GHz: 20 dBm
• Antennas (2) External Dual-Band Omni Antennas 2.4 GHz: 3 dBi, 5 GHz: 4 dBi
• Wi-Fi Standards 802.11 a/b/g/n/r/k/v/ac
• Wireless Security WEP, WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES)
• BSSID Up to 8 per Radio
• Mounting Wall/Pole/Fast-Mount (Kits Included)
• Operating Humidity 5 to 95% Noncondensing
• Certifications CE, FCC, IC
• VLAN 802.1Q
• Advanced QoS Per-User Rate Limiting
• Guest Traffic Isolation Supported
• WMM Voice, Video, Best Effort, and Background
• Concurrent Clients 250+
