Victron Energy MultiPlus‑II Inverter Chargers 3000, 5000VA, 8000, 10,000 & 15000kVA
The MultiPlus‑II merges all features of the MultiPlus and MultiGrid: advanced inverter‑charger capability, anti‑islanding grid compliance, plus an optional external current transformer for true PowerControl and PowerAssist operation.It is available in multiple DC‑voltage and power classes: 12 V or 24 V for 3000 VA, 24 V or 48 V for 5000 VA, and higher 48 V models for 8000, 10 000 or 15 000 VA
Features & Benefits:
- Hybrid “Swiss Army” Functionality : Combines pure‑sine inverter, battery charger, UPS behavior, generator interface and grid‑tied operation in one unit. In Tanzania this suits mixed applications: solar backup for homes, small businesses, lodges, telecom sites, rural clinics.
- PowerControl & PowerAssist : Ideal where grid supply is limited or costly. Settings avoid overloads, and supply peak loads using stored battery power without needing oversized generators. External CT ensures only net power is fed/exported.
- Scalable to High Power : Units easily paralleled or set up in three‑phase to power large residential or commercial installations—modular upgrade path up to >50 kVA.
- ESS Integration & Monitoring : Supports Victron’s ESS (Energy Storage System) logic for solar self‑consumption and zero export control. Enables automation (via Venus GX or similar) to dynamically optimize battery/grid usage with remote data via VRM Portal.
- Robust Build for Harsh Conditions : Operating temperature from −40 to +65 °C, up to 2000 m altitude, high humidity tolerance. Well suited for Tanzania’s heat and dust if installed with ventilation
Use Cases:
- Rural or semi‑urban off‑grid estates powered by solar PV + storage, with generator backup. MultiPlus‑II handles load sharing, UPS, charger, anti‑islanding.
- Grid‑plus‑PV residential systems, optimizing solar self‑consumption, avoiding expensive grid import peaks or load shedding limits.
- Telecom towers and small business sites, where high reliability and seamless switchover matter.
- Guest lodges or remote resorts needing combined solar/generator hybrid systems with flexible configuration.
Value Proposition & Local Positioning:
- Reliable brand backed by Davis & Shirtliff: distribution and support in Dar es Salaam.
Modular scalability: suits varied budgets and future growth (start with 5 kVA, expand to 15 kVA or multi‑unit networks). - Value‑added features: such as generator auto‑start, remote monitoring via smartphone/VRM, programmable alarms, make it attractive over basic inverter brands.
- Suitable for local grid limits: PowerAssist helps avoid overload fees or nuisance trips for limited mains supply common in some Tanzanian areas.
Technical Specifications
Specification Category | 48 V / 3000 VA – 8000 VA | 48 V / 10,000 VA | 48 V / 15000 VA |
---|---|---|---|
PowerControl / PowerAssist | Yes (with external CT) | Yes | Yes |
AC Input Voltage | 187–265 VAC, 45–65 Hz | Same | Same |
Max Feed-through Current | 100 A | 100 A | 100 A |
Continuous Output Power | 6400 W | 8000 W | 12000 W |
@40 °C | 5500 W | 7000 W | 10000 W |
@65 °C | 4000 W | 6000 W | 7000 W |
Peak Power | 15000 W | 18000 W | 27000 W |
Maximum Efficiency | 95% | 95% | 96% |
No-load Power (standby) | 29 W | 38 W | 55 W |
No-load AES Mode | 19 W | 27 W | 39 W |
No-load Search Mode | 3 W | 4 W | 6 W |
Charger Absorption Voltage | 57.6 V | Same | Same |
Float Voltage | 55.2 V | Same | Same |
Storage (eco) Mode Voltage | 52.8 V | Same | Same |
Charger Current | 110 A | 140 A | 200 A |
External AC Current Sensor (option) | Up to 100 A | Up to 100 A | Up to 100 A |
Programmable Relay | Yes (multi-function) | Same | Same |
Communication Ports | VE.Bus, general-purpose ×2 | Same | Same |
Operating Temp. Range | −40 °C to +65 °C | Same | Same |
Max Altitude | 2000 m | Same | Same |
Enclosure Material | Steel, blue (RAL 5012) | Same | Same |
Protection Rating | IP22 | Same | Same |
Safety Standards | EN-IEC 60335-1,-2-29; EN-IEC 62109-1,-2 | Same | Same |
EMC Standards | EN 55014-1,-2; EN-IEC 61000-3-2,-3; IEC 61000-6-1,-2,-3 | Same | Same |
Anti-Islanding | Compliant (certificates available) | Same | Same |
