Technical Specification
- Output Power: 6000W/6000VA continuous power with pure sine wave output for clean, stable electricity.
- Solar Input: Maximum 6kW solar panel capacity with 500VDC open circuit voltage and 120-450VDC MPPT range.
- Battery Compatibility: 48V DC system with 120A maximum charging current from both AC and solar sources.
- Grid Integration: 230VAC nominal with selectable voltage range (170-280VAC for computers, 90-280VAC for appliances)
- Communication Interfaces: RS485, RS232, USB, WiFi, CAN, and dry contact for comprehensive monitoring and control.
- Physical Specifications: Compact 350ร420ร114mm dimensions, 11.5kg weight, LCD & LED display panel.
- Protection Systems: Output overload, input high voltage, short circuit, over discharge, and over charge protection.
- Environmental Rating: -10ยฐC to 50ยฐC operating temperature, 5-95% humidity tolerance, IP20 dust protection.
- Safety Compliance: IEC/EN62109-1/2 safety standards, EN61000-6 series EMC compliance for reliable operation.
- Generator Support: Compatible with backup generators for triple-redundant power security.
