Technical Specification
- 20kVA/20kW capacity suitable for high-density server environments and critical infrastructure applications.
- Input voltage range: 230V (1-phase) or 380V/415V (3-phase) with hard-wire installation (5-wire 3P+N+E or 3-wire 1P+N+E)
- Output voltage: 220V/230V/240V with voltage regulation of ±1% static and ±5% dynamic load.
- Double-conversion online technology provides zero transfer time to battery during power events.
- Integrated network management card enables remote monitoring and control via web browser, SNMP, and Telnet.
- Advanced battery management system extends battery life through temperature-compensated charging.
- Scalable runtime with optional external battery packs (requires compatible battery frames)
- Operating temperature range: 0-40°C, suitable for Tanzania’s tropical climate conditions.
- Audible noise at 1 meter from surface of unit: 55.0 dBA, appropriate for office environments.
- Communication interfaces: Network management slot, Serial port, USB port, Emergency Power Off, Relay output contacts.
